$879.53
Portable Hand Winch Lifter
This lift is easy to maneuver with 4″ x 1″ wheels, two rigid, two locking swivel. Features a removable platform with adjustable forks underneath for increased versatility. Platform size is 21″ wide by 19-1/2″ long. The handle length on the hand crank may be adjusted to increase or decrease lifting/lowering speeds. Lifts 2-1/2″ per rotation.
| Uniform Capacity (lb.) | 330 |
|---|---|
| Fork Length (in.) | 19-1/2 |
| Fork Length (in.) | 19-1/2 |
| Fork Width (in.) | 2 |
| Back Wheel Width (in.) | 1 |
| Front Wheel Width (in.) | 1 |
| Minimum Fork Height (in.) | 3 |
| Maximum Fork Height (in.) | 43-1/2 |
| Platform Width (in.) | 21 |
| Platform Length (in.) | 19-1/2 |
| Assembled Weight | 110 |
| Total Ship Weight | 213 |
| Package 1 Size | 40″W x 48″D x 64″H |
| Freight | LTL Palletized |
| Weight | 213 lbs |
|---|---|
| Dimensions | 48 × 40 × 64 in |
| Uniform Capacity (lb.) | 330 |
